FRONT VIEW PICTURE SHOWN WITH OPTIONAL ACCESS HOLE INSERTS
Part Number:
403

Seismic Rack Cabinets, 2500 LB NEBS Certified, Closed Sided Enclosures


$1,874.00 $1,846.00
(No reviews yet)
Made in USA
31:
Rack unit locations silkscreened on front rails
27:
Available in 3 Overall Widths: 28", 32" AND 36"
28:
Overall Height 84", Usable Height: 77" high (44RU)
30:
2 - Pair of mounting rail with cable access holes, 11 Gauge metal
33:
1- grounding assemble, grounds one set of rails to the cabinet
34:
Frame constructed from 10 gauge steel
200:
IF YOU HAVE ANY QUESTIONS OR YOU CAN'T FIND WHAT YOU ARE LOOKING FOR PLEASE CONTACT US.
81:
Powder Coat Finish
80:
NEBS ZONE 4 Earthquake GR-63-CORE Certified, 2000 Pound Load
29:
2 - ESD Jacks, mounted one on the front and one on the back frame

Accessorize Your Product

    Description

     Solid sided seismic rack cabinet, NEBS certified zone 4 earthquake GR-63-Core, with 2000 pounds load. This is a heavy-duty welded steel frame construction, high heat and high weight telecommunications data rack.



    - Top Panel with cut out for cable pass through,
    - Base with cut out for cable pass through.
    - Grounding holes provided also.


    An earthquake can wreak havoc on hardware in a data center or server room, which is why it is crucial to have computer racks and enclosures that comply with industry standards that address earthquakes. In general, there are two standards you'll read about when it comes to seismic rated computer racks: Telcordia Technologies GR-63-CORE Network Equipment Building Systems (NEBS) requirements and the International Building Code (IBC). More often than not, the former will used for certification but both address earthquake protection.

    In order to achieve GR-63-CORE NEBS certification, a manufacturer must submit an application to a third-party certifier. This third-party will test the computer rack loaded at full capacity using a shaker table to simulate an earthquake. It can be tested for different zones to determine the level of earthquake it can withstand. Zone 4 is the most intense level and reserved for areas where there is heavy seismic activity. Additionally, Zone 4 is the most stringent certification process.

    If your data center is in need of earthquake protection to stay running, no matter the circumstances, Gaw Technology seismic server racks are Zone 4-certified for the highest level of protection. They can handle a 2,000 lb. load and are made of heavy-duty steel for extreme durability.  Finally, our seismic computer racks are made in-house for added quality assurance.
